Anderson SB350 Polycarbonate Battery Connector 350A
Anderson Power Products SB350 SB Series 350 Amp Connector, Polycarbonate Annderson SB 350 Connector
The Anderson SB350 Polycarbonate Battery Connector 350A is a heavy-duty, two-pole connector for high-current applications, widely used in battery systems and electric vehicles. It features a durable polycarbonate housing and silver-plated copper contacts for reliability.
Key Features & Specifications
The SB 350 connector is designed for power capabilities up to 500 amps with a 350 mcm wire (or up to 450 amps with 4/0 AWG wire) and a 600V AC/DC maximum voltage rating.
| Current Rating | 350A (rated current) |
| Voltage Rating | 600V AC/DC max |
| Housing Material | Polycarbonate (PC) or a chemical-resistant PBT/PC blend |
| Contacts | Silver-plated solid copper for low resistance |
| Wire Size Range | #1/0 (53.5 mm²) to 350 mcm (150 mm²) |
| Operating Temperature | -20°C to +105°C (standard housing) |
| Design | Genderless, allowing identical housings to mate with each other |
| Safety Features | Mechanically keyed by color to prevent incorrect connections; UL 94V-0 flammability rating |
