SB-50 Battery Connector
SB-50 Battery Connector
Contact Seller :- Call or Whatsapp +91 9354676493 happy@qysmt.in
Contact Seller :- Call or Whatsapp +91 9354676493 happy@qysmt.in
Call or Whatsapp
+91 93544 02545
Email: vitika@qysmt.in
SB50 Battery Connector 50 Amps 600V
SB50 Connector Set 600V 50A, SB50 Connectors, Connector For Battery Connection SB 50
The SB50 connector is a heavy-duty, 2-pole connector widely used for high-current DC applications like battery connections and power inverters, featuring a 50 amp current rating and 600 volt maximum voltage rating
Key Features and Specifications
The SB50 connector is designed for reliability and safety in demanding environments.
| Current Rating | 50 A (UL rated for hot plugging up to 50 A) |
| Voltage Rating | 600 V (AC or DC operation) |
| Wire Gauge Range | 16 AWG to 6 AWG (1.3 mm² to 13.3 mm²) |
| Contact Material | Silver-plated copper alloy for low resistance and durability |
| Housing Material | Impact-resistant polycarbonate, often flame-retardant |
| Operating Temperature | -20°C to 105°C |
| Design | Genderless and hermaphroditic, allowing identical connectors to mate with each other |
| Safety Features | Mechanical keys (color-coding) prevent accidental cross-mating of circuits with different voltages or amperages (e.g., grey only mates with grey) |
Common Applications
These connectors are the industry standard for high-performance power connections.
- Battery systems: Widely used for connecting auxiliary batteries in campers, trailers, and caravans.
- Power management: Ideal for UPS systems, power inverters, and solar power devices.
- Electric vehicles: Heavily utilized in various electric vehicle batteries (e.g., 48V, 60V, 72V systems).
- Industrial use: Suitable for a range of industrial power supply needs due to their robust and damage-resistant design.
