Sc-4-0/G Fuji contactor DC24V 1NC
Technical Specifications

• Brand/Series:  SC Series (DC Operation Type without case cover)
• Model Code: SC-4-0/G (Coil: 24V DC, Aux: 1NC / 1b)
• Rated Operational Current (AC-3): 18A (at 200–240V), 13A (at 380–440V)
• Motor Capacity (AC-3): 3.7 kW at 220V, 5.5 kW / 7.5 kW up to 440V
• Resistive Load (AC-1 / Ith): 25A
• Auxiliary Contacts: 1NC (designated as 1b by Fuji, indicating normally closed)
• Coil Voltage: 24V DC
• Dimensions (H x W x D): 108 mm x 81 mm x 53 mm
• Approvals/Standards: IEC 60947-4-1, EN, VDE, UL, CSA, CE
