SC-E02P fuji contactor 220vac
Key Specifications

• Rated Operating Current (AC-3): 9A for three-phase motors (200V to 440V).
• Rated Carrying Current (AC-1): 20A for resistive loads.
• Main Contacts: 3 Normally Open (N.O.) poles.
• Coil Voltage Options: Available in multiple versions including 24V, 100V, 110V, 200V, 220V, and 440V AC.
• Mounting: Compatible with 35 mm DIN rail or screw mounting (M4).
• Dimensions: Approximately 81 mm (Length) x 43 mm (Width) x 81 mm (Height).

Model VariantsThe specific coil voltage is often appended to the model name. Common versions include:

• SC-E02P-110VAC: Standard 110V AC coil.
• SC-E02P-220VAC: Standard 220/240V AC coil.
• SC-E02P/G: DC-operated version (e.g., 24V DC).
• SC-E02RM: Reversible version for motor direction control

Applications & Features

• Motor Control: Typically used for squirrel-cage motors up to 4kW at 380/440V.
• Elevator Systems: Often utilized in elevator control systems and funicular cars.
• Safety: Incorporates an IP20 finger-protection structure to prevent accidental contact with live parts.
• Certifications: Complies with international standards including IEC 60947-4-1, UL, CSA, and TUV.
