SC-E1P 220V Fuji contactor

SC-E1P 220V Fuji contactor
Key Specifications

• Brand/Series: Fuji Electric SC-E Series (Model: SC-E1P)
• Coil Voltage: 220V AC (50Hz) / 240V AC (60Hz)
• Number of Poles: 3-pole (3 main power contacts / N.O. poles)
• Rated Operating Current: 32A for AC-3 motor loads (200–440V); 50A for AC-1 resistance loads
• Terminal Type: Ring terminals / direct wiring compatible with integrated finger-protection and box lug construction
• Mounting: 35mm DIN rail (Top Hat rail) or screw mounting (M4)
• Standards Compliance: IEC 60947-4-1, EN 60947-4-1, UL, and CSA certified
