SC-N5 110v Fuji AC contactor 110vac
Specifications & Features

• Model / Series: Fuji SC-N5 (SC Series Super Magnet type)
• Coil Voltage: 110V AC (50/60Hz)
• Rated Current (Ith / AC-3): 105A conventional thermal current / 93A operational current
• Poles: 3-Pole main contacts
• Auxiliary Contacts: Typically equipped with configurable auxiliary blocks (e.g., 2NO + 2NC or up to 5NO+2NC depending on the specific factory variant)
• Standards: Conforms to IEC 60947-4-1, UL 508, and JIS C 8201-4-1
