SCOSb 10 S04NC RD-K-PNP SO SCHMALZ VACUUM GENERATOR
Key Specifications & Breakdown

• Product Family (SCPSb): A series of compact ejectors featuring an integrated basic module made of high-strength plastic, open silencers, and quick-connect push-in couplings.
• Nozzle Size (10): Features a 1.0 mm nozzle diameter.
• Connection (S04): Built for 6mm hose push-in connections (Hose D6 for both compressed air supply and vacuum).
• Control Valve Type (NC): Normally Closed. The ejector only generates a vacuum when electrical power is supplied to the internal solenoid control valve.
• RD-K-PNP SO: Indicates the electrical and signal configuration, featuring digital vacuum monitoring utilizing a PNP switching output for signal feedback.

Performance Data
