SDR-480-24 MEANWELL Power supply
Key Specifications

• Output Power: 480W
• Output Voltage: 24V DC (adjustable from 24V to 28V DC)
• Output Current: 20A
• Input Voltage Range: 90–264 VAC (or 127–370 VDC)
• Efficiency: Up to 94%
• Dimensions: 85.5 mm x 125.2 mm x 128.5 mm (W x H x D)
• Mounting: DIN rail TS-35 / 7.5 or 15
• Operating Temperature: -25°C to +70°C
• Protections: Short circuit, overload, over voltage, and over temperature
• Certifications: UL508, TUV BS EN/EN62368-1
