SF-50 Digital Push-Pull Tester

Digital Push Pull Meter/Tester SF-50 for Tension and Compression Load Destructive Tests,
SF-50 Digital Push Pull Tester.

The SF-50 is a portable digital force gauge used to measure both push and pull forces for a wide range of applications. It is commonly used in manufacturing, product development, quality control, and various industrial settings to perform tests such as tension, compression, and destructive testing.

• Measurement capabilities: The SF-50 is a push-pull meter, designed to measure both tensile (pull) and compressive (push) forces.
• Capacity: The maximum load value is 50 Newtons (N), which is equivalent to 5 kilograms (kg) or 11 pounds (lb).
• Accuracy: The accuracy is typically around ±0.5%, with a load division value of 0.01N.
• Display: It features a large, easy-to-read LCD digital display.
• Measurement units: The gauge supports switching between three different units: N, kg, and lb.
• Power: It is powered by an internal 3.7V lithium battery, offering a theoretical working time of up to 15 hours.
• Accessories: It comes with several connectors, such as hook, point, and flat push connectors, to accommodate different test types.
• Additional functions: Key features often include a peak value hold function to record the maximum force applied and an automatic shutdown feature to save battery life.

• Electronics: Testing the insertion and withdrawal force of connectors.
• Hardware and automotive: Measuring the push and pull force of mechanical components.
• Light industry and textiles: Checking load strength and material resistance.
• Quality control: Performing destructive and non-destructive tests on products to ensure they meet specifications.

Specification/Additional Details

• Model Name/Number : SF-50

• Display Type : LCD

• Usage/Application : Push-Pull Tension and Compression Load Destructive Tests

• Power Source : Internal 3.7V Lithium Battery

• Battery Life : 15 hours

• Max. Load value : 50N/5kg/11lb

• Measurement Unit : N / Lb / kg.
