SFT-06-150W SMT filter

SFT-06-150W SMT filter
Technical Specifications

• Type: Suction filter / strainer without case.
• Bore Diameter / Thread: Rc 3/4 inch ISO pipe connection.
• Filtration Rating: 150 Mesh (150W).
• Filter Material: Pleated stainless steel wire gauze (SUS).
• Compatible Fluid: General mineral-based hydraulic oils.
• Physical Dimensions: 72 mm height and 62 mm outer diameter.

Key Features

• Pleated Design: Maximizes the filtration surface area while saving internal tank space.
• Cleanable & Reusable: Stainless steel construction allows the mesh to be washed and reinstalled.
