SGDV-1R6A11A Servo motor Assay

SGDV-1R6A11A Servo motor Assay
Technical Specifications

• Brand/Series: Yaskawa Sigma-V (SGDV)
• Model Code: SGDV-1R6A11A
• Power Rating: 0.2 kW (200 W)
• Input Voltage: 3-Phase or 1-Phase 200–230 VAC (50/60 Hz)
• Communication: MECHATROLINK-II reference type

Testing & Evaluation OverviewWhen performing an assay, diagnostic check, or functional test on this SERVOPACK, technicians generally follow a structured bench-test procedure:

• Visual & Nameplate Inspection: Verify model number, input ratings, and check for physical capacitor damage or burnt components.
• Power Input Check: Apply control power (1-phase) and main power (3-phase 200V AC) safely while monitoring for error codes on the LED display.
• Communication & Enable Test: Connect via MECHATROLINK-II to clear alarms, release hardware/software interlocks, and test command response with a compatible test motor. []
• Output Voltage Verification: Check phase outputs (U, V, W) under a commanded low-speed rotation to ensure balanced output phases without short circuits.

If you need further help with this unit, please tell me:

• What error code or alarm is the drive showing?
• Are you looking for wiring diagrams, parameter settings, or troubleshooting steps
