SGT967360 Celduc Solid-State Relays

SGT967360 Celduc Solid-State Relays
Key Technical Specifications:

• Model Number: SGT967360
• Type: 3-Phase Solid State Relay (SSR)
• Operating Voltage: 24 - 600 VAC
• Load Current: 75 Arms (per phase)
• Control Voltage: 8.5 - 30 VDC
• Switching Type: Zero-cross
• Dimensions: 45 mm / 47.6 mm housing width
• Protection Rating: IP20

Features and Applications:

• Applications: Designed for heating elements (resistive loads) and motor control.
• Design: Part of the compact Sightpac® range.
• Efficiency: High-efficiency, durable relay suitable for heavy-duty industrial environments.
• Terminals: Standard screw terminals on the power side.
