SHF-001T-0 JST Connector Terminal
SHF-001T-0 JST Connector Terminal
Contact Seller :- Call or Whatsapp +91 9319902096 harshita@qysmt.in
Contact Seller :- Call or Whatsapp +91 9319902096 harshita@qysmt.in
Call or Whatsapp
+91 9319902096
Email: harshita@qysmt.in
Key Technical Specifications
- Applicable Wire Gauge: Accepts wire sizes ranging from 22 AWG to 28 AWG (\(0.08\text{ mm}^2\) to \(0.33\text{ mm}^2\)).
- Current and Voltage Rating: Supports a maximum current of 3A AC/DC and a maximum voltage of 250V AC/DC.
- Material & Plating: Constructed from durable Phosphor Bronze with a Tin (Sn) plating finish for enhanced conductivity and corrosion resistance.
- Insulation O.D. Range: Compatible with outer insulation diameters from 1.2 mm to 1.7 mm.
- Operating Temperature: Functions reliably within a temperature range of -25°C to +85°C.
Compatibility & Applications
This terminal is designed exclusively for use with JST NH and SM Series connector housings. It is heavily utilized across industrial automation, consumer electronics, and automotive signal routing due to its high contact pressure and robust arm-lock mechanism.
