SL-205NA-W Photoelectric sensor

SL-205NA-W Photoelectric sensor
Technical Specifications

• Housing Shape: L-shaped micro-slot
• Sensing Distance / Slot Width: 5 mm to 6 mm
• Operating Supply Voltage: 5V to 24V DC
• Output Type: NPN open-collector (Normally Open + Normally Closed)
• Control Modes: Selectable Light-on / Dark-on
• Response Frequency: High speed at 3 kHz (Response time ≤ 0.33 ms)
• Light Source: Infrared LED (Wavelength: 940 nm)
• Connection Method: 2-meter, 4-wire pre-wired electrical cable
• Built-in Protection: Surge protection and reverse polarity protection
• Operating Temperature Range: -25°C to +55°C
