Azbil SL1-PK Limit Switch Azbil

Azbil Yamatake SL1-PK Short Roller Lever Limit Switch 0.1A, 125V AC 30V DC, SPDT, 1 NC 1 NO, SNAP Action, Gold Contacts, 4.0 N max. Operating Force

Specification/Additional Details

• Switch Type : Lever Limit Switch
• Model Name/Number : SL1-PK
• Contact Voltage Ac Max : 250V
• Degree Of Protection : IP54
• Current Rating : 0.1 Amps
• max. operating force : 4.0 N

• max. pretravel : 2 mm

• min. overtravel : 4 mm

• Movement differential : 0.3 mm

• Lever : Short roller lever
