SMC CRB1BW50-180S vane-style pneumatic rotary actuator

SMC CRB1BW50-180S vane-style pneumatic rotary actuator

Key Technical SpecificationsBased on manufacturer data from SMC and Misumi, the primary specifications include:

• Bore Size: 50 mm.
• Rotation Angle: 180°.
• Vane Style: Single Vane (Standard for 180° rotation).
• Shaft Type: Double Shaft.
• Operating Pressure Range: 0.15 to 1.0 MPa (approx. 1.5 to 10 bar).
• Cushioning: Internal rubber bumpers to reduce impact and increase reliability.
• Ports: 1/8" thread size, typically located on the body side.
• Temperature Range: 5°C to 60°C.
