SMC MKB16-30RNZ pneumatic rotary clamp cylinder

Name: SMC MKB16-30RNZ pneumatic rotary clamp cylinder
Brand: QYSMT
Availability: InStock

Contact Seller :- Call or Whatsapp ‪+91 9319902096 harshita@qysmt.in

Call or Whatsapp
‪+91 9319902096

Email: harshita@qysmt.in

Product variants

Quantity

SMC MKB16-30RNZ pneumatic rotary clamp cylinder

Part Number Breakdown

According to official specifications from SMC Pneumatics and industrial suppliers like the product configuration breaks down as follows:

MK: Series designation (Rotary Clamp Cylinder).
B: Mounting configuration (Through-hole / Both ends tapped style).
16: Bore size diameter (\(16\text{ mm}\)).
30: Clamp stroke length (\(30\text{ mm}\)).
R: Rotary direction (Clockwise / Right-hand rotation during the clamping stroke).
N: Rod tip shape (Features a female thread design).
Z: New design standard (Upgraded MK-Z line with integrated auto-switch mounting grooves).

Key Specifications & Features

Space-saving Profile: Designed with auto-switch mounting grooves built directly into all four side faces, ensuring that any attached magnetic sensor switches remain flush with the block body without projecting outward.
Robust Clamping: The internal mechanism generates a structural clamping force of approximately \(0.075\text{ kN}\) under optimal factory operating pressures.
Interchangeability: It maintains exact identical mounting dimensions to older-generation MK series cylinders, making it a drop-in replacement for existing machinery setups.
