SMC RB1007 Shock Absorber

RB1007 SMC RB1007 Shock Absorber

The SMC RB1007 is a compact, non-adjustable shock absorber used in pneumatic systems and industrial machinery to absorb impact and reduce noise.

• Functionality: It automatically adjusts to provide the most appropriate energy absorption performance, making it suitable for a wide range of collision speeds and loads.
• Design: It features a robust steel body with a fully threaded design for easy installation, a hardened stainless steel piston rod, and is designed for high-speed, low-load or low-speed, high-load applications.
• Specifications:
  • Connection Type: M10 x 1 thread size.
  • Stroke: 7 mm.
  • Max. Energy Absorption: 5.88 J per cycle.
  • Max. Impact Force: 422 N.
  • Operating Temperature: -10 to 80°C.
  • Weight: Approximately 23 g.
