SMT Stencil Screen Tension Meter AS-120N

Tension Gauge Digital Display Screen Tension Tester AS-120N Tensiometer, Tension Meter AS-120N, AS-120N Digital Screen Tension Tester, AS-120N Tension Gauge ...

The AS-120N is a digital handheld tension meter used for measuring the tension of wire and steel mesh in screen printing and stencil manufacturing. It provides a precise, numerical reading on an LCD screen, which helps to eliminate the errors that can occur with manual, tactile measurement.

• Digital LCD display: Shows a clear, precise reading of the screen's tension.
• Measurement range: 7 to 40 N/cm (Newtons per centimeter).
• High resolution: The display has a resolution of 0.1 N/cm.
• Unit conversion: Allows for switching between N/cm and kg/cm.
• Data output capability: Can connect to a PC via USB or RS-232 data output for logging measurements.
• Portability: The compact, lightweight design (around 490g without batteries) makes it easy to use and transport.
• Power source: Uses four 1.5V AAA (UM-4) batteries.
• Standard accessories: Comes with a calibration block, carrying case, and an operation manual.

• Screen printing: Ensures consistent print quality by confirming the screen mesh is stretched to the correct tension.
• Electronics manufacturing: Measures tension in SMT (Surface Mount Technology) stencils to ensure accurate solder paste deposition.
• Quality control: Provides a reliable method for production facilities to track and verify screen and stencil quality.
