snv 188.062040 Wieland Safety Relay

snv 188.062040 RELAY
Key Technical Specifications

• Brand / Manufacturer: Wieland
• Model / Part Number: SNV 4063KL-A (R1.188.0620.0)
• Supply Voltage: 24 V DC
• Safety Contacts: 2 normally open (NO) immediate paths and 1 time-delayed NO path
• Time Delay Range: 0.15 to 3 seconds (configurable)
• Safety Rating: Category 4 / PL e (ISO 13849-1), SIL 3
• Dimensions: 22.5 x 96.5 x 114 mm
• Mounting Type: DIN rail

Core Features

• Cross Wire Monitoring: Detects short circuits across input channels.
• Reset Monitoring: Supports manual or automatic reset with a monitored start button.
• Application: Ideal for controlled stop functions where power must be maintained briefly before safely cutting off a machine.
