Soldering Iron Bit/Tip ETB Chisel Shape Soldering Tip
Weller ETB Soldering Tip/Bit ETB ET Screwdriver Tip Style
The Weller ETB soldering tip is a screwdriver-shaped tip for use with various Weller soldering irons and stations. The "ET" designates the series of tips, and the "B" specifies the screwdriver shape with a 2.4 mm width.
Specifications
- Tip shape: Screwdriver/chisel.
- Tip width: 0.093 inches (2.4 mm).
- Tip thickness: 0.020 inches (0.51 mm).
- Tip reach: 0.625 inches (15.9 mm).
- Material: Solid copper core, plated with iron, nickel, and chromium for efficient heat transfer and durability.
- Sensor hole: Includes a stainless steel liner in the base to prevent the tip from seizing to the sensor.
Compatible Weller models
The ET series of tips are compatible with a variety of Weller soldering stations and pencils. Compatible models include:
WE1010, WE1010EDU, WES51/50, WESD51, LR21, WEP70, PES50, PES51, WCC101, EC1201A, EC1204A
