Weller LTB Soldering Iron Tip/Bit Chisel Shape Soldering Tip

LTB Chisel Shape Soldering Tip 2.4mm, Weller LT Series LTB Soldering Tip Chisel 2.4mm

The Weller LTB soldering tip is a chisel-shaped tip designed for precision and universal soldering applications. It is part of Weller's LT Series of soldering tips.

Product specifications

• Tip shape: Chisel
• Tip dimensions:
  • Width: 0.094 inches (2.4 mm)
  • Thickness: 0.031 inches (0.79 mm)
• Materials: Constructed from solid copper, plated with iron, and finished with a nickel-chromium coating for durability and heat transfer efficiency.
• Primary applications: Universal electronics soldering, including through-hole and some surface-mount tasks

Compatible soldering irons and stations

The LTB tip is compatible with several Weller soldering tools:

• Weller WSP80 soldering pencil

• Weller WP80 soldering pencil

• Weller WXP80 soldering pencil

• Weller WD1002 digital soldering station

• Other LT series-compatible stations and irons
