Soldering Station Soldering Iron Bit T12-D32 Screwdriver-shaped Soldering Tip

Soldering Iron Bit/Tip T12-D32 for Hakko Soldering Rework Station N5W5 FX-951 FX-95

The T12-D32 is a screwdriver-shaped soldering tip, most notably produced by Hakko and compatible with Hakko FX-951 soldering stations and similar models. The "D" in the model number refers to the flat-blade, or screwdriver, shape, and the "32" indicates the tip width, which is 3.2 mm. This type of tip is versatile and well-suited for various applications due to its shape.

• Shape: The D-series is a flat-blade, or "screwdriver," shape. This design allows you to use the tip in two different ways: by applying the flat side for a wide line contact or by using the narrower edge.
• Size: The tip has a width of 3.2 mm. This larger surface area is ideal for transferring a good amount of heat efficiently.
• Applications: It can be used for general-purpose soldering and drag soldering across multiple pins. It is suitable for larger components, thick terminals, and correcting solder bridges.
• Compatibility: The T12 series tips are primarily used with Hakko FX-951, FX-950, and FM-203 soldering stations. Third-party manufacturers also produce compatible T12-D32 tips for these and other stations.
