SP-200-24 Power module

SP-200-24 Power module
Core Specifications

• Output Voltage: 24V DC
• Output Current: 0 to 8.4A max
• Total Power Capacity: 201.6 Watts
• Input Voltage Range: 85 ~ 264 VAC or 120 ~ 370 VDC (Universal / Full Range)
• Efficiency: 83% to 85%
• Wiring Interface: Heavy-duty low-voltage and mains screw terminals

Key Technical Features

• Active PFC Function: Includes a built-in active Power Factor Correction (PFC) filter with a power factor rating greater than 0.93 to improve energy efficiency.
• Built-in Protections: Full safety protections against short-circuits, power overloads, over-voltage spikes, and internal over-temperature failures.
• Constant Current Limiting: Includes a specialized internal limiting circuit to prevent equipment damage during initial power surges
