SPS-C3010 Power module

SPS-C3010 Power module
Technical Specifications

• Brand/Series(often distributed under partner brands like DHRUVPRO or NICE-POWER).
• Input Voltage: Dual voltage configuration supporting AC 110V/220V at 50Hz/60Hz.
• Output Power: 300W maximum.
• Output Ranges:
  • Voltage: 0–30V (Resolution: 0.01V).
  • Current: 0–10A (Resolution: 0.001A).
• Regulation Performance: Line and load voltage regulation are exceptionally tight at less than 5mV.
• Ripple & Noise: Low noise footprint keeping ripple under 5mVrms (100mVp-p)
• Display: High-precision 4-digit LED display showing voltage, current, and active power wattage.

Key Features

• Dual Operating Modes: Automatically switches between Constant Voltage (CV) and Constant Current (CC) configurations depending on the connected load.
• Integrated USB Charging Interface: The standard model comes equipped with a 5V/2A USB port. Upgraded "S" iterations (like the SPS-C3010S) boast dual USB-A and USB-C outputs supporting multiple modern fast-charging protocols (QC3.0, PD3.0, Apple, etc.).
• Hardware Protections: Built-in protection layers shield connected electronics against Over-Voltage Protection (OVP), Over-Current Protection (OCP), Over-Temperature Protection, and short-circuits.
• Encoder Adjustment: Features precise double-potentiometer tuning for fine or coarse voltage/current changes. High-end variants use clickable encoder dials with a toggleable audio mute function.
• Smart Cooling System: An automated thermal sensor triggers a temperature-controlled fan that regulates heat dissipation dynamically to ensure lower ambient noise.
