sqa309 METAL CLAMPED SQUEEGEES 535MM 60 15 MM OVERHANG

sqa309 METAL CLAMPED SQUEEGEES 535MM 60° ~ 15 MM OVERHANG
Product Specifications

• Part Number: SQA309.
• Length: 535mm.
• Print Angle: 60° (standard for normal paste filling of apertures).
• Overhang: 15mm (the length of the free-moving metal plate without holder support).
• Material: Typically features a stainless steel blade clamped into a precision-machined aluminum holder.
• Application: Solder paste printing on DEK series stencil printers.
• Packaging: Usually sold as a pair (set of two).

Key Benefits for SMT Printing

• Improved Deposit Quality: The metal blade design eliminates "pumping" and "scavenging," ensuring a cleaner solder paste deposit compared to polyurethane alternatives.
• Enhanced Stencil Life: Features a smooth, lubricated edge that reduces pulling and stretching of the stencil, which improves pad registration.
• Adjustability: The clamping mechanism allows for easy interchangeability of blades and adjustment of blade flexibility based on specific application requirements.
• Efficiency: Designed to minimize paste waste and reduce maintenance downtime.
