Ionizer ST-503A 600mm Air Bar

ST-503A Ionizer Bar, Anti-static Bar ST-503A, ST-503A Anti-static Elimination Stick Device, ESD Bar ST-503A Ionizing Stick, ST-503A Ionizing Bar

Ion Wind Bar ST-503A Ionizer 600mm Anti-static Bar Anti-static Elimination Stick designed to remove static electricity from the surfaces of objects, such as film, packaging, and electronics, as they move along a production line.

The ST-503A is an anti-static bar that works in conjunction with a high-voltage generator to produce a balanced stream of positive and negative ions.

Features :

• Static removal: It is designed to remove static electricity from the surfaces of objects, such as film, packaging, and electronics, as they move along a production line.
• Uniform ionization: The bar ensures a uniform supply of positive and negative ions across the entire area it covers, which is critical for fine static removal in sensitive environments.
• Industrial applications: The device is commonly used in manufacturing processes to prevent electrostatic discharge (ESD) from damaging components. Its industrial design makes it suitable for use in factories and workshops.

Specification/Additional Details

• Eliminator Type : Ionizing Bar
• Operating Voltage : 7 kV
• Current Consumption : 0.36 mA/M
• Air Pressure : 5-7 Kg
• Air Flow Rate : 10 m/sec
• Max Bar Length : 6 m

• HV Cable Length : 2 m

• Operating Temperature : -10 to 50 DegreeC

• Relative Humidity : < 60%

• Working Distance : With compressed air supply 200-1500mm (optimum 250-300mm)

• Size (Length) : 600mm; 350mm, 1,100mm (standard); customized 200-2000mm
