• STSM-1240 CKD Cylinder

• Model Breakdown (STSM-1240):
  • STS/STM: Refers to the CKD Guided Cylinder series (often super compact).
  • 12: Refers to the bore size, which is 12mm in diameter.
  • 40: Refers to the stroke length, which is 40mm.
• Key Features & Specifications:
  • Type: Double-acting guided pneumatic cylinder.
  • Structure: Square, space-saving body designed to reduce total length and integrate guide rod bearings for enhanced reliability.
  • Material: Usually light alloy/aluminum.
  • Operating Pressure: Typically 0.7–1.0 MPa (7–10 bar).
  • Function: Guided movement allows for high precision and resistance to side loads.
• Applications:
  • Used in automated machinery for lifting, pushing, or clamping applications, particularly where space is limited.
• Similar Models:
  • STSM-12-30: 12mm bore, 30mm stroke.
  • STSM-0840: 8mm bore, 40mm stroke.
  • STSM-2025: 20mm bore, 25mm stroke.
• Common Search Queries & Marketplace Identifiers:
  • 1pcs New CKD Cylinder STSM12-30/40.
  • CKD STSM-12-30 Double Rod Compact Air Cylinder. CKD +9

For precise, up-to-date specifications, it is recommended to consult the official CKD STM/STS series catalog.
