Riko SU18-NP Photo Sensor

Riko U-type Photoelectric Switch SU18-NP Sensor NPN/PNP, NO/NC, 18 mm Detection distance, Infrared LED 940nm, DC12 ~ 24V Operating voltage, Pre-wired Ø4.2 x 2 M 4-wire, IP65
RIKO Sensor SU18-NP U-type Photoelectric Switch Sensor

Specification/Additional Details

• Sensor Type : U-type Photoelectric
• Brand : Riko
• Model : SU18-NP
• Detection distance : 18mm
• Minimum detection object : Opaque ( Dia.1.0 x 10.0mm )
• Light Emitter : Infrared LED 940nm

• Operating voltage : DC12 ~ 24 V

• Current consumption : 30 mA Max

• Output Type : NPN L.on / D.on, PNP L.on / D.on

• Response Time : 1ms Max

• Ambient lighting : Incandescent lamp: Max. 5,000 lux

• Tensile strength : AC500V 60Hz for 60 seconds

• Operating temperature : -10 DegreeC ~ +55 DegreeC

• Wiring method : Pre-wired Dia.4.2 x 2 M  4-wire

• Protection level : IP65
