SV605NS2R8I Innovance drive
Core Technical SpecificationsAccording to industrial technical data and listings from platforms like the drive carries the following hardware specifications:

• Power Rating: 400W output capacity.
• Input Voltage: Single-phase (1PH) AC 200–240V, 4.0A at 50/60Hz.
• Output Rating: Three-phase (3PH) AC 0–240V, 2.8A continuous current, 0–500Hz output frequency.
• Communication Interface: Integrated EtherCAT network ports (IN/OUT) for high-speed, synchronized multi-axis network control.
• Physical Integrity: Features an external aluminum heatsink for passive thermal dissipation and carries up to an IP54 environmental protection rating.

Model Number BreakdownThe model code SV630NS2R8I details the system parameters:

• SV630N: The overarching product family consisting of compact network-type AC servo drives.
• S2R8: Specifies the rated current rating, mapping to 2.8 Amps of continuous output current.
• I: Signifies the communication variant, establishing EtherCAT bus communication as the primary control protoco
