SY3120-5LOZE-M5 SMC SOLENOID VALVE

SY3120-5LOZE-M5 SMC SOLENOID VALVE
Key Specifications

• Series: SY3000
• Valve Type / Ways & Positions: 5-Way / 2-Position, Single Actuation
• Voltage: 24V DC
• Port Size: M5 x 0.8
• Electrical Entry: L-type plug without connector (with light/surge voltage suppressor - 'OZE' specification)
• Operating Pressure Range: 0.1 to 0.7 MPa
• Power Consumption: 0.35 W (with power-saving circuit design)
• Seal Material: H-NBR (rubber seal with improved ozone resistance)
• Features: Built-in strainer in the pilot valve to prevent debris clogs

You can source or check local vendor inventory and specifications for similar units via distributors like or reference technical background directly froIf you'd like, let me know:

• Are you looking to purchase a replacement unit or troubleshoot an installation?
• Do you need details on compatible manifolds or wiring accessories?
