SY3120-5LZD-M5 , SY3420-5LZD-M5 SMC valve

SY3120-5LZD-M5 , SY3420-5LZD-M5 SMC valve

Part Number Breakdown

• SY3: Represents the SMC SY3000 Series base body size.
• 1 vs 4 (Type of Actuation):
  • SY3120: Configured with a 2-position single solenoid mechanism.
  • SY3420: Configured with a 3-position exhaust center mechanism.
• 2: Designates a body-ported design style.
• 0: Standard pilot specification type.
• -5: Specifies a 24V DC power source voltage requirement.
• LZ: Equipped with an L-type plug connector featuring a 300mm lead wire.
• D: Outfitted with a built-in indicator light and a protective surge voltage suppressor.
• -M5: Connects via a standard metric M5 thread size for the air ports.

• Operating Medium: Compressed air filtered to 5 microns or less.
• Pressure Range: Operates smoothly from 0.1 MPa to 0.7 MPa.
• Temperature Limit: Accommodates ambient and fluid temperatures up to 50°C.
• Seal Material: Utilizes robust rubber seals for extended operational lifespans.
• Manual Override: Includes a non-locking push/push-turn locking type override for physical maintenance checks.
