SY3120-5MOU-C6-Q SOLENOID VALVE

SY3120-5MOU-C6-Q SOLENOID VALVE
 Part Number BreakdownEvery character in this part number specifies a exact feature of the valve:

• SY: Valve Series (SY Series)
• 3: Series size (SY3000 Series, 10mm width)
• 1: 2-Position Single Actuation (single solenoid coil with spring return)
• 2: Body Ported configuration
• 0: Internal Pilot type
• -5: 24V DC Rated Voltage
• M: M-type plug connector
• O: Without connector cable (includes light and surge voltage suppressor)
• U: Non-polar electrical specification
• -C6: Built-in 6mm One-Touch push-in fittings for piping
• -Q: European standard CE compliance marking
