SYJ3123-5LZ-M3 solenoid valve

 SYJ3123-5LZ-M3 solenoid valve

According to data from Motion Industries and Misumi USA, here are the key specifications for the SMC SYJ3123-5LZ-M3 valve:

• Function: 5-port, 2-position, single solenoid valve.
• Fluid: Air.
• Operating Pressure Range: 0.15 to 0.7 MPa (approximately 21.7 to 101.5 psi).
• Coil Rated Voltage: 24 VDC.
• Electrical Entry: L-type plug connector with lead wire (300 mm length).
• Power Consumption: 0.35 W.
• Port Size: M3x0.5 thread size for connections.
• Mounting Style: Body ported.
• Body Material: Die-cast zinc.
• Manual Override: Non-locking push type.
• Features: Includes indicator light and surge voltage suppressor.
