SZR-LY2-N1 24VDC Honeywell relay
Product Overview
Brand: Honeywell Sensing and Productivity Solutions (SZR-LY Series)
Part Number: SZR-LY2-N1 24VDC
Relay Type: General purpose, non-latching cube-type power relay
Coil Voltage: 24 VDC
Contact Arrangement: DPDT (Double Pole Double Throw / 2 Form C)
Contact Current Rating: 10 A
Max Switching Voltage: 250 VAC / 125 VDC
Coil Resistance: 650 Ohms
Features: Built-in LED indicator
Mounting Style: Plug-in / socket mount (panel mount compatible)
Contact Material: Silver Cadmium Oxide (AgCdO)
Dimensions: 28 mm x 21.5 mm x 36 mm (Weight: approx. 35 g)
If you'd like, let me know:
- What socket or mounting base you need to pair with it
- Whether you are looking for alternative brands or pin-compatible equivalents
I can help you find the right setup.
