T-102 Analog Wire Tension Meter

Yokogawa Wire Tension Meter T-102 T-102-01-00 Unit Newton, Yokogawa T-102 Analog Tension Meter

The T-102 is a dial-type tension meter used for measuring the tension of electrical wires and other materials with thick denier. It is a mechanical device that is held in the hand and features rollers that the wire passes over to measure its tension.

• Measurement range: The T-102 series comes in four main versions with different ranges:
  • 01-00: 0 to 10 N (least count: 0.2 N)
  • 02-00: 0 to 20 N (least count: 0.5 N)
  • 01-10: 0 to 1 kg (least count: 20 g)
  • 02-10: 0 to 2 kg (least count: 50 g)
• Application: The device is designed for industrial applications and is suitable for measuring the tension of thick denier or electric wires. It can also be used for yarns, fibers, and other linear materials.
• Design: It is a spring-based system with a dial-type display for easy reading. The rollers feature precision ball bearings for smooth operation and accurate readings.
• Accuracy: The accuracy is within ±1 graduation.
• Build: The housing is made of black ABS resin.
• Compared to other meters: The T-102 allows for a larger refraction angle of the sampled item compared to similar existing tension meters.
