Soldering Station Tip T12-BC1 Bevel Soldering Iron Tip

Hakko T12-BC1 75W Soldering Station Tip

The T12-BC1 soldering tip is a high-quality, high-power bevel tip designed for T12-series soldering stations. It is well-suited for drag soldering, pre-tinning wires, and general electronic assembly and repair. Bevel (cut at a 45° slant). This design allows users to utilize different contact points with varying sizes.

Specifications

• Brand: Hakko (also compatible versions by other brands)
• Tip Shape: BC1 Bevel. This is a cylindrical tip with a slant-cut end.
• Tip Size: 1 mm (diameter) by 11.5 mm (length) for the bevel face.
• Angle: 45-degree slant.
• Material: High-grade copper, with plating for high anti-oxidation and excellent thermal conductivity.
• Maximum Power: 70W–75W, depending on the compatible soldering station.
• Temperature Range: 200°C–480°C.
