Soldering Station Tip T12-C08 Bevel-type Soldering Iron Tip

Bevel (0.8 C ) T12-C08 Soldering Bit 0.8mm Soldering Tip Hakko

The T12-C08 is a high-precision, bevel-type soldering tip primarily used for fine and detailed electronics soldering. It is part of the T12 series, which features an integrated heater and sensor for fast and consistent heating.

• Tip shape: Bevel, or "Shape C". It has a slanted, conically-shaped tip cut at a 60° angle.
• Tip dimensions: 0.8mm bevel width and 12mm length. The angled shape allows for flexible contact, using the point for precision work or the wider face for larger joints.
• Performance features
  • Fast heat transfer: The integrated heating element and sensor within T12 tips allow for rapid heat-up and efficient temperature recovery.
  • Durability: Made with oxygen-free copper and multi-layer electroplating for high-temperature resistance and oxidation resistance, ensuring a long lifespan.
  • Lead-free compatibility: Designed to be effective for lead-free soldering applications.
• Recommended applications:
  • Drag soldering: Ideal for soldering multiple pins on components like ICs and connectors.
  • Pre-tinning lead wires: Efficient for pre-tinning and preparing lead wires for soldering.
  • Versatile soldering: Well-suited for a wide range of general-purpose and precision soldering jobs.
• Compatible stations: The T12-C08 is compatible with soldering stations that use T12 series tips, including popular Hakko models such as:

• • Hakko FX-951, Hakko FX-950, Hakko FX-952, Hakko FM-203, Hakko FM-204, Hakko FM-206, Accta 401, Various other T12-compatible stations.
