Takex DL-S5R Photoelectric Sensor

Takex Photoelectric Sensor DL-S5R Background Suppression Photo Sensor Diffuse, NPN open collector, Light-On/Dark-On Selectable (with switch), 10-50mm Range, Red LED, 0.35ms max. Response time, 2 m Cable, Polyarylate (Case and lens), 12-24V DC

Specification/Additional Details

• Sensor Type :  Background suppression photo sensor (Distance limited reflection)
• Brand : Takex
• Model : DL-S5R
• Control output : NPN open collector
• Operation mode : Light-ON/Dark-ON selectable (with switch)
• Detection range : 10~50mm

• Response time : 0.35ms max.

• Light source: Red LED (700 nm)

• Indicator : Operation indicator: Red LED/Stability indicator: Green LED

• Material : Case and lens: polyarylate

• Operating temperature : -25° ~ +55°C (non-freezing)

• Connection : 4 core, 2 m length, black cable
