Sefar TENSOCHECK 100 Digital Tension Meter

Sefar Tensocheck 100 Mesh Tension Measuring Gauge, Sefar Tensocheck 100 Digital Tension Measuring Device

The SEFAR TENSOCHECK 100 is a digital tension meter designed for precise and reproducible measurement of mesh tension in industrial applications, particularly for screen printing. Its key features include a digital display for easy reading, high accuracy, and a battery-powered design for portability.

• Manufacturer: Sefar.
• Measurement range: 4 to 60 N/cm (Newtons per centimeter).
• Resolution:
  • 0.2 N/cm for readings below 30 N/cm.
  • 0.5 N/cm for readings of 30 N/cm or higher.
• Accuracy (Tolerance): The accuracy varies depending on the measured tension:
  • 10–19.8 N/cm: $\pm$0.4 N/cm
  • 20–29.8 N/cm: $\pm$0.6 N/cm
  • 30–39.5 N/cm: $\pm$1.0 N/cm
  • 40–50.0 N/cm: $\pm$1.5 N/cm
• Power: 3.7V lithium-ion battery, rechargeable via USB-C cable. It also features an automatic shut-off function to conserve battery life.
• Usability: The device is designed for easy operation without special training and provides a clear, high-contrast digital display.
• Durability: Features a robust construction for consistent performance in demanding industrial environments.

Specification/Additional Details

• Brand : Sefar
• Model Name/Number : TENSOCHECK 100
• Type : Digital Tension Meter
• Resolution : Range <30 N/cm, +-0.2 N/cm, Range >30 N/cm, +-0.5 N/cm
• Voltage : 3.7V Battery Powered
• Battery : 3.7 V, 7.2 Wh lithium ion battery rechargeable via USB C cable
