QYSMT
TH632 Digital counter meter
TH632 Digital counter meter
Contact Seller :- Call or Whatsapp +91 9319902096 harshita@qysmt.in
Contact Seller :- Call or Whatsapp +91 9319902096 harshita@qysmt.in
Call or Whatsapp
+91 9319902096
Email: harshita@qysmt.in
TH632 Digital counter meter
| Meter Type | Electromechanical |
| Mounting | Panel Mount |
| Counting Range | 0–99999.9 h |
| Supply Voltage | 200V |
| Display Type | Digital |
| Reset Type | Manual Reset |
| Housing | Square |
| Ingress Protection | IP67 |
| Backlight | LED Backlight |
| Application | Compressor, Panel, DG Set, Vehicle, Machine Tool |
| Availability | In Stock |
TH632 Panasonic Hour meter 200V ~ 50/60Hz 1.5 W
Product SpecificationsAccording to various datasheets and product pages, the Panasonic TH632 hour meter has the following key specifications:
Product SpecificationsAccording to various datasheets and product pages, the Panasonic TH632 hour meter has the following key specifications:
- Rated Operating Voltage: 200 V AC
- Operating Voltage Range: 85 to 115% of rated operating voltage
- Rated Frequency: 50/60 Hz (selectable by a switch)
- Rated Power Consumption: Approx. 1.5 W
- Counting Range: 0 to 99999.9 hours
- Minimum Time Display: 0.1 hours (6 minutes)
- Reset Function: No reset button (TH63 series)
- Mounting Type: Panel mount (DIN half size: 24 x 48 mm)
- Terminals: Flat terminals (#187) for easy wiring
- Rotary Indicator: Features a rotary indicator (one turn every 72 seconds) for monitoring operation
- Approvals: CE, UL, and CSA compliant
- Ambient Temperature: -10 to +50°C
