Through Beam PG-602 KEYENCE SENSOR, Sensing Range: 0-300 mm
| Sensor Type | Through Beam |
| Sensing Range | 0-300 mm |
| Output Type | NPN |
| Supply Voltage | 10-30 V DC |
| Body Style | Fork Type |
| Protection Rating | IP67 |
| Brand | Keyence |
| Availability | In Stock |
PG-602 KEYENCE SENSOR
Key Technical SpecificationsThis sensor head must be paired with an amplifier unit (typically the KEYENCE PG-610) to function.
Key Technical SpecificationsThis sensor head must be paired with an amplifier unit (typically the KEYENCE PG-610) to function.
- Detecting Area: ().
- Minimum Detectable Object: Opaque materials as small as () in diameter.
- Light Source: Infrared LED.
- Response Time: Ultra-fast .
- Output: NPN open-collector, max (can be converted to PNP using the OP-5148 adapter).
- Environmental Resistance: Operates between () and is resistant to sunlight up to .
- Self-Diagnostic Output: Includes an alarm that triggers if the lens is dirty, the cable is disconnected, or the sensitivity is too low, simplifying maintenance.
- Adjustable Sensitivity: Features a 1-turn trimmer for fine-tuning based on the application.
- Off-Delay Timer: Selectable delay of or to ensure stable signals to a PLC. Easy Mounting: The sensor head window can be opened or closed, allowing it to be mounted onto existing pipes without needing an open end.
