TKC600 BR Current Hall Sensor 4V 600A Mesin Las TKC 600 BR
TKC600 BR Current Hall Sensor 4V 600A Mesin Las TKC 600 BR
Contact Seller :- Call or Whatsapp +91 9319902096 harshita@qysmt.in
Contact Seller :- Call or Whatsapp +91 9319902096 harshita@qysmt.in
Call or Whatsapp
+91 9319902096
Email: harshita@qysmt.in
TKC600BR Current Hall Sensor 4V 600A Mesin Las TKC 600 BR
Key Specifications
- Rated Primary Current (\(I_{pn}\)): 600 Amperes (A)
- Measurement Range: 150A to 900A (depending on peak pulse thresholds)
- Standard Output Voltage: \(\pm \)4.0 Volts (V) at the rated current
- Supply Voltage (\(V_{c}\)): \(\pm \)15 Volts DC
- Operating Principle: Open-loop Hall Effect technology
- Aperture Dimensions: 20.5 mm × 10.5 mm rectangular window for primary cable or busbar insertion
Main Application
- Welding Equipment: Monitors output current loops in heavy-duty welding machines to maintain a stable arc.
- Variable Speed Drives: Measures DC link or AC motor phase currents.
- Power Supplies: Provides overcurrent protection and feedback control loops in Uninterruptible Power Supplies (UPS) and switch-mode power supplies (SMPS).
- Battery Management: Tracks charge and discharge currents in industrial battery banks.
Technical Advantages
- Galvanic Isolation: Isolates low-voltage monitoring microcontrollers from high-power electric currents.
- High Linearity: Guarantees that the output voltage scales linearly with the input current for precise monitoring.
- Low Power Consumption: Minimizes circuit losses compared to traditional shunt resistors.
