TL-W3MB1 Omron sensor

TL-W3MB1 Omron sensor
Key Technical SpecificationsBased on the Omron TL-W Datasheet, here are the core performance metrics:

• Sensing Distance: 3 mm ( 10%) with a set distance of 0 to 2.4 mm.
• Output Type: 3-wire DC, PNP open collector, Normally Open (NO).
• Power Supply: 12 to 24 VDC (operating range 10 to 30 VDC).
• Response Frequency: 600 Hz.
• Control Output: 100 mA maximum switching capacity.
• Environmental Protection: IP67 rated (dust-tight and water-resistant).
• Housing Material: Heat-resistant ABS plastic.
• Dimensions: Ultra-compact rectangular body (approx. 10 x 6 x 27 mm).
