TOR13 ON/OFF/ON button shake head switch

TOR13 ON/OFF/ON button shake head switch
Key Specifications

• Switch Action: ON / OFF / ON (with spring return/automatic reset to center)
• Pole/Throw: SPDT (Single Pole, Double Throw) or SPCO
• Electrical Rating: 10A at 250VAC or 15A at 250VAC (depending on the specific sub-model)
• Mounting Hole: 12mm diameter
• Terminals: Screw, solder, or tab type

How the Action WorksBecause this switch is designed to spring back, it is ideal for applications where you need temporary control in two directions, such as a directional motor, winch, or hoist.

• Center Position: OFF (circuit is open).
• Press/Push Lever Up (Maintained or Momentary): Engages the first circuit.
• Press/Push Lever Down (Maintained or Momentary): Engages the second circuit.
