TP-4-4141A024 (084275) Euchner limit switch

TP-4-4141A024 (084275) Euchner limit switch
Technical Specifications

• Model Number: TP4-4141A024M
• Order/ID Number: 084275
• Supply Voltage: 24 V DC/AC
• Thermal Current (\(I_{th}\)): 4 A
• Contact Configuration: Slow-action contacts (door position + solenoid monitoring)
• Enclosure Protection: IP67
• Cable Entry: 3 x M20 x 1.5
• Housing Material: Rugged reinforced thermoplastic

Key Features

• Guard Locking: Operates on the power-to-lock (closed-circuit current) principle.
• Auxiliary Release: Allows manual unlocking of the safety guard during power loss or setup.
• Industrial Application: Designed for heavy industrial machine safety doors and interlocking hatch systems.
