TR422-01Y-T Limit sensor

TR422-01Y-T Limit sensor

Product Type: Mechanical limit / position switch
Model: TR422-01Y-T
Operating Principle: Mechanical (roller plunger type)
Mechanical Details
Actuator Type: Roller plunger
Housing Material: Grey cast iron, galvanized
Mechanical Life: Up to 10 million operations
Actuating Angle: ±30°
Actuating Speed:
Min: 1 mm/min
Max: 0.5 m/s
Electrical Details
Contact Type: 1 NC (Normally Closed)
Switching Principle: Slow action
Rated Insulation Voltage (Ui): 400 V
Thermal Test Current: 16 A
Utilization Category: AC-15 (400 VAC, 4 A)
Connectivity
Connection Type: Screw terminals (M20 x 1.5)
Cable Size: 1.5 mm² to 2.5 mm²
Environmental Conditions
Protection Class: IP65
Operating Temperature: -30°C to +90°C (standard)
Dimensions
Size (L×W×H): 63 × 106 × 117 mm
