TSXCUSB 485 Make:Schnider

TSXCUSB 485 Make:Schnider

Key Features and CompatibilityThe TSXCUSB485 functions as a communication device that converts serial signals to RS485 via a USB connection. It connects to a PC via a USB connector and to the processor with an 8-pin mini-DIN connector. Power is typically drawn from the USB port, and it supports baud rates from 300bps to 1Mbps. The cable is compatible with several Windows operating systems, including XP, Win7, Win8, Win10, and Win11. A rotary switch on the converter allows for selecting different serial mode functions and provides line polarization for Modbus. Supported Devices and SoftwareThe TSXCUSB485 is compatible with various Schneider Electric hardware, including Modicon Premium, Atrium, Twido, Micro, Nano, and Naza series PLCs. It also works with Magelis HMI terminals, OTB, XBTN/R/S, and TeSys T motor management systems. The cable supports Schneider Electric software that uses Modbus or Unitelway protocols, such as TwidoSuite, Advantys, PL7, Unity Pro/Control Expert, and Vijeo Designer Lite.
