Digital Sonic Tension Meter U 550

UNITTA U-550 Gates Unitta Sonic Tension Meter, Digital (sonic) Belt Tension Meter U-550, Belt Tension Meter U-550, UNITTA U-550 Sonic tension Meter, Gates UNITTA Sonic Belt Tension Meter U-550

The Gates Unitta U-550 is a digital sonic tension meter used to measure the tension of power transmission belts by analyzing their vibrational frequency. It is suitable for measuring multi-ribbed, V-belts, and synchronous belts in industrial settings.

• Measurement principle: The device uses a sensor to detect the natural frequency of a plucked belt. It then processes the signal through a high-performance computer to display the tension measurement digitally.
• High accuracy: The U-550 provides high-accuracy readings ±1%.
• Wide frequency range: The meter can measure a broad frequency range from 10 Hz to 5,000 Hz, with three adjustable ranges (LOW, STANDARD, and HIGH).
• PC data output: The device features data output to a PC, allowing for easy data management and record-keeping via a USB connection.
• Large memory: The internal memory can store up to 500 of the latest measurement results.
• Intuitive display: An Organic EL (OLED) display provides a clear, high-resolution output of the measurement data.
• Automated functions: It includes an auto-trigger function, automatic background noise cancellation, and an auto-power-off feature to save battery life.
• Robust design: The compact and lightweight meter is designed for ease of use in industrial settings.
• Multiple sensor options: Depending on the specific application, different sensors are available, including flexible, cord, and electromagnetic types.

• Accuracy and repeatability: Reduces human error in belt tensioning, leading to more consistent and accurate installations.
• Optimal drive performance: Proper belt tension is critical for ensuring optimum performance and reliability of belt drive systems.
• Proactive maintenance: Consistent tension measurement helps extend the life of belts and other drive components.
• User-friendly: The meter's design, auto functions, and data storage make it easy to use for all levels of expertise.

Specification/Additional Details

• Product Type: Belt Tension Meter
• Brand: UNITTA
• Model: U-550
• Frequency range: 10-5000hz
• Tension value: 0.01-99900N
• Supply: Alkaline battery (Triple A Type x 2 pieces).
• Data output: RS-232C interface for connecting to a PC.
• Operating conditions: Temperature range of -10°C to 50°C and humidity of less than 85% RH.
• Units: Displays measurements in Hertz (Hz), Newtons (N), pounds (lb), and kilograms (kg).
