Pepperl+Fuchs UB6000-F42-I-V15 Ultrasonic Sensor

Pepperl+Fuchs Ultra Sonic Sensor UB6000-F42-I-V15 Diffuse Reflective Sensor 350 to 6000 mm Sensing Range, 400 to 6000 mm Adjustment Range, 10 to 30 V DC Operating Voltage, ripple 10 %SS, 1 Analog output 4 to 20 mA Output type, IP54, ABS

Specification/Additional Details

• Sensing Distance : 6000 mm
• Product Type : Ultrasonic Sensor
• Type of Sensing : Diffuse Reflective
• Brand : Pepperl+Fuchs
• Model : UB6000-F42-I-V15
• Sensing Adjustment Range : 400 to 6000 mm

• Dead Band : 0 to 350 mm

• Standard target plate : 100 mm x 100 mm

• Transducer frequency : approx. 65 kHz

• Response delay : approx. 650 ms

• Operating voltage : 10 to 30V DC , ripple 10 %SS

• Output type : 1 analog output 4 to 20 mA

• Default setting : evaluation limit A1: 400 mm , evaluation limit A2: 6000 mm , wide sound lobe

• Resolution : 0.7 mm

• Connection type : Connector plug M12 x 1 , 5-pin

• Degree of protection : IP54

• Material Housing : ABS
